Multiprotocol Radio

RC radio to controle all your drone ( Wifi, Bluetooth, Frsky, DSMX, Flysky, Hubsan, ... )

Processors:

• CPU: Xtensa dual-core 32-bit LX6 microprocessor, operating at 240 MHz and performing at up to 600 DMIPS
• Ultra low power: co-processor
• Memory: 520 KiB SRAM
• Flash: 4 MByte
• PSRAM: 8 MByte ( Optional )

Features:

• 2.4" Tactile TFT 24bit Color LCD Display QVGA (320x240)
• x4 12-bit ADC input ( Use for gimbal )
• x8 10-bit ADC input ( Optional )
• x2 Shoulder buttons
• uSD card slot
• Passive piezo buzzer
• Front RGB led

Wireless connectivity:

• Wi-Fi: 802.11 b/g/n/e/i
• Bluetooth: v4.2 BR/EDR and BLE
• CC2500 from Texas Instrument (Frsky, Futaba SFHSS)
• NRF24L01 from Nordic Semiconductor (Hisky, Bayang, Syma, Assan and other Chinese models)
• A7105 from Amiccom (Flysky AFHDS2A, Hubsan)
• CYRF6936 from Cyprus Semiconductor (DSM/DSMX, JR Pro, Walkera DEVO)


Video
